MTU MTU/18V2000G65 diesel generator sets features:
Supply Scope
• Engine include air, fuel, oil filters, starting motor and charge alternator etc.
• Brushless AC alternator, single bearing, flange connection, with AVR
• Radiator with engine driven fan mounted on skid
• Channel steel base frame, <550KW base 8hrs mounted fuel tank as standard
• Anti-vibration pads between engine/alternator and base frame
• Circuit breaker 3P as standard, 4P optional
• Auto control panel
• Start battery with connecting cable and floating battery charger
• Flexbile pipe, exhaust elbow, industrial silencer etc.
• Standard tools kit
• Electric drawing, test report ,operation & maintaince manual of generator etc.
•Optional soundproof/Container canopy, ATS cabinet, remote control panel, synchronization panel, movable trailers, heat exchanger, remote horizontal water tank system, external fuel tank, etc
| Manufacturer | Changsha Mingbang Intelligent Technology Co.Ltd | ||||||
| Model | MB-M910 | ||||||
| Prime Powder | 910KW/1137.5KVA | ||||||
| Power Factor | COSΦ=0.8(lagging) | ||||||
| Max. Output current | 1638A | ||||||
| Genset Weight | 9000kg(Net) | ||||||
| Length x Width x Height (Engine) (mm) | 4750×2000×2380mm | ||||||
| Voltage | 400/230V | ||||||
| Frequency | 50HZ | ||||||
| Engine Specification | |||||||
| Manufacturer | Benz Engine | ||||||
| Model | MTU/18V2000G65 | ||||||
| Rated speed | 1800rpm | ||||||
| Standby Powder | 1100KW/1375KVA | ||||||
| Fuel Consumption | ≤205g/kw.h | ||||||
| Lube oil capacity | 130 L | ||||||
| Bore (mm) x Stroke (mm) | 130×150 mm | ||||||
| Displacement (litre) | 35.82 | ||||||
| Coolant capacity, L | / | ||||||
| Configuration | 18 cylinder V-type, four stroke, water air cooling | ||||||
| Cooling | Liquid Cooled | ||||||
| Governor type | Electronic | ||||||
| Starting voltage | 24 Volts DC | ||||||
| Filtration system | Air Filter/Fuel Filter/Oil Filter | ||||||
| Alternator Specification | |||||||
| Manufacturer | Changsha Mingbang Intelligent Technology Co.Ltd | ||||||
| Model | MBV6E | ||||||
| Voltage Regulator | AVR | ||||||
| Voltage adjust range | ±1% | ||||||
| Rated Voltage/Frequency/Factor | 400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire | ||||||
| Steady-state Frequency | 5% | ||||||
| No-load Voltage Adjust Range | >=95%-105% | ||||||
| Insulation Class | H | ||||||
| IP Protection | 22 | ||||||
| Excitation Type | Blushless | ||||||
| Rated power | Engine | Alternator | Control panel |
| 24kw~1500kw | Cummins | Stamford Leroy somer Marathon Mecc alte ABB Chinese alternators | Deepsea ComAp Harsen Smartgen |
| 36kw~18+00kw | Perkins | ||
| 68kw~560kw | Volvo | ||
| 20kw~200kw | Deutz | ||
| 40kw-2200kw | Yuchai | ||
| 50kw-2200kw | Weichai | ||
| 540kw-1900kw | Mitsubishi | ||
| 50kw-800kw | SDEC | ||
| 650kw~2200kw | Chinese engine |
Our factory
Our factory has CCEC, DCEC, VOLVO, PERKINS,MTU,Deutz, Daewoo, SDEC, Weichai,Jichai etc. World and Chinese famous engine for generators set. We have specialized in synchronous 100%copper wire alternator for more than 20 years. MB brand alternator has been expanded all over the world. The power range of our generator is from 6.5KW~2000KW.
Open Type 910KW MTU Diesel Generator Low Fuel Consumption 1137KVA Electric Brushless Diesel Generator Set
<<<<<Changsha Mingbang Intelligent Technology Co., Ltd.>>>>>>>
1.Mingbang is devoted to the R&D and manufacturing of diesel generator sets since 2005
2. Mingbang new factory covers an area of 5042 square meters located in Jiang du industrial park of Yang zhou city.
3.Mingbang quality certified by ISO9001 & ISO14001 Management System to guarantee high quality products and service.
5.Mingbang maintaining long term strategic friendship cooperation with domestic and abroad famous manufactures of Cummins, Perkins, Doosan, SDEC, Mitsubishi(SME), Deutz, Wuxi Wandi, Leroysomer, Stamford, and Marathon etc.
6.We have so wide products ranges from 5kva to 3000kva for the diesel generator set; power from 25kva to 1500kva for gas generator set;
7.Soundproof/weather proof type, container type generator set; movable, vehicle type generator sets. Regarding to the electrical control systems, it covers Auto control panel, Synchronization panels, ATS etc.
8.Mingbang can also provide customized solution due to customer requirements upon our standard product supply in order to meet the demand of market. To focus on global market, create mingbang as international brand, and constantly improve our quality level and maximize customer profitability is our unchangeable promise and eternal pursuit.
